Electric Traveling Single Girder Overhead Cranes Capacity 7.5m Span 20m Lifting Height 6m

Electric Traveling Single Girder Overhead Cranes Capacity 7.5m Span 20m Lifting Height 6m

Electric Traveling Single Girder Overhead Cranes Capacity 7.5m Span 20m Lifting Height 6m
Electric Traveling Single Girder Overhead Cranes Capacity 7.5m Span 20m Lifting Height 6m

Large Image :  Electric Traveling Single Girder Overhead Cranes Capacity 7.5m Span 20m Lifting Height 6m Get Best Price

Product Details:
Place of Origin: Zhejiang, China
Brand Name: Nante
Model Number: SG 7.5t-20m
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: N/A
Packaging Details: Naked
Delivery Time: Within 2 months
Payment Terms: L/C, T/T
Detailed Product Description
Color: Red Lifting Height: 6m
Capacity: 7.5T Brand: Nante
Span: 20m Safety Components: Load Limiter, Cross Travel Limiter, Long Travel Limiter
High Light:

design overhead crane

,

overhead electric cranes

,

heavy cargos single girder overhead cranes

Electric Single Girder Overhead Bridge Cranes Traveling Type Capacity 7.5m Span 20m Lifting height 6m

Overhead crane is used inside of the workshop for lifting and transfering heavy cargos from one place to another. It has a wide range of applications like steel works, marble factory, storage and warehouse etc. Single girder bridge crane is particularly usable when light weight handling tasks are required. It is easy for intallation and mantainance.
If you plan to build a workshop, and have any purchase needs, please feel free to contact us for proposals on budget.
I believe our factory scale can satisfy you with both design and fabrications. What we need is only a good chance to proof ourselves.
Welcome to visit our factory or website for more details.
Note: As one custom designed crane, the exact price shall be decided after your configurations.

The capacity, span, height, traveling and hoisting speed, working classification and usage etc. Basic particulars should be offered.

DESIGN:
Compact dimensions, low weight, easy to operate and easy to maintain, modular design with direct fits between components


Structure:
Bridge Girder, End carriages, Crab Frame manufactured from box plate design / Rolled Sections. If required 100% radiography of all butt welding joints of bridge and end carriages can be provided.


MOTORS:
Nante Crane uses sturdy cylindrical/ conical rotor pole-changing motors with elegant continuous cast aluminum sections, integrated safety brakes insulation class F, IP54 protection.


CONTROLS:
Pendant control from floor, master control switches, master controllers in the driver's cabin can be provided. Radio remote control can be provided on request.


ELECTRICAL PANEL:
Modular design, covering a very wide operating range. The systems are designed for ease of installation and maintenance and reliable operation, with fuseless circuitry, ducted wiring and non-screwed terminals. Each drive group is equipped with a motor overload protection device to provide effective protection against inadmissible overloading.

PAINTING:
Every component & part is thoroughly scrubbed & painted with two coats of primer before assembly & two coats of synthetic enamel after testing.



Technical Parameters

      3.2T
  Span m 10.5 14 17.5 21 24.5
Speed Lifting Speed m/min 5/0.8
Trolley Speed 5.0/20
Bridge Speed 8/32
Motor Power Lifting Motor kW 3.2/0.45 3.2/0.45 3.2/0.45 3.2/0.45 3.2/0.45
Trolley Motor 0.64x1 0.64x1 0.64x1 0.64x1 0.64x1
Bridge Motor 0.37x2 0.37x2 0.37x2 0.55x2 0.55x2
Crane Power 4.58 4.58 4.58 4.94 4.94
Basic Data Max.Wheel Load KN 20.8 22.8 24.8 27.3 31.4
Wheel Dia.   125 125 125 125 125
Model of End Carriage   HSE125-15 HSE125-20 HSE125-25 HSE125-30 HSE125-35
Gear Model   SK0282-0.37 SK0282-0.37 SK0282-0.37 SK0282-0.55 SK0282-0.55
Crane Wheel Qty. Pcs 4 4 4 4 4
Crane Rail   30×50 30×50 30×50 30×50 30×50




Single girder overhead industrial crane with hoist are widely used in the following applications:
1. LIGHT DUTY Cranes for maintenance, warehouse and assembly operations.
2. MEDIUM DUTY Cranes for general engineering application and Machine shop.
3. HEAVY DUTY Cranes for Heavy machine shops, paper mills, Fabrication shop, etc.
4. EXTRA HEAVY DUTY Cranes for continuous operation in Steel mills and other Heavy Engineering purpose. Cranes for Outdoor duty is also designed specially.
