5T Single Girder Overhead Cranes,
Light Duty Overhead Travelling Crane,
5T Load Single Girder EOT Crane
Light duty electric Single girder overhead cranes travelling crane with 5T load capacity
LDX model single girder overhead crane 5t is designed in accordance with European standard with compact structure, small wheel pressure, which carries out effective use of limited plant space, and reduce the cost of plant structure.
LD model single girder overhead crane 5t is widely used in machinery manufacturing, metallurgy, ports, railway stations, warehouses and other occasions, providing more efficient logistics solutions, especially for accurate positioning operation.
|Motor Power||Lifting Motor||kW||9.5/1.5||9.5/1.5||9.5/1.5||9.5/1.5||9.5/1.5|
|Basic Data||Max.Wheel Load||KN||58.7||61.4||64.7||68.6||74.5|
|Model of End Carriage||HSE200-15||HSE200-20||HSE200-25||HSE250-30||HSE250-35|
|Crane Wheel Qty.||Pcs||4||4||4||4||4|
Design features include:
Bridge Girder, End carriages, Crab Frame manufactured from box plate design / Rolled Sections. If required 100% radiography of all butt welding joints of bridge and end carriages can be provided.
Nante Crane uses sturdy cylindrical/ conical rotor pole-changing motors with elegant continuous cast aluminum sections, integrated safety brakes insulation class F, IP54 protection.
Variable Frequency Drives & Remote Controls:
We also offer Variable Frequency Drive in hoisting, cross travel, long travel for stepless speed control as an optional feature. We also provide radio remote control cranes for application in inaccessible and hazardous areas.
Failsafe magnetic or hydraulic brakes of 150% torque or more are fitted on shaft extensions. For heavy duty cranes a second brake can be mounted to ensure failsafe operation.
Pendant control from floor, master control switches, master controllers in the driver's cabin can be provided. Radio remote control can be provided on request.
Weight overload protection device, Top quality long time bearing polyurethane materials buffer, Crane traveling limit switch, Voltage lower protection function, Emergency stop system, current overload protection system and so on!
