Product Details:
Payment & Shipping Terms:
|
| Capacity: | 500 KG | Lift Height: | 4 M |
|---|---|---|---|
| Work Duty: | M3 | Distance Between Two Hooks: | 1.22 M |
| Lifting Speed: | 7.2 M/min | Power Supply: | 3P 380V |
| High Light: | 0.5 tonne electric chain hoist,500kg hoist chain |
||
500kg NANTE Brand 380V 50Hz Double Hook Electric Chain Hoist IP54 with Pendant Control
| Capacity | 500 KG |
| Lift Height | 4 m |
| Work Duty | M3 |
| Distance between two hooks | 1.22m |
| Lifting speed | 7.2 m/min |
| Power supply | 3P 380V |
Brief Description:
Composed by cable reel, wire rope, electric motor, brake, pendant/remote and other components, the electric hoist has such characteristics as compact structure, easy installation, low cost and so on, which can be widely used in workshop, factory and other place to lift heavy load.
Details:
1. Electric Trolley
Single speed: 11 or 21 m/min
Double speed: 5 & 20m/min
Inverter can be optional
2. Exquisite Shell
Aluminum alloy
Solid &light
3 times powder coating
3. Safe Brake System
Mechanical side brake
More safer and sensitive
4. Load Chain
UItra heat-treatable alloy
G80:Japan FEC or Germany
More sturdy and durable
5. Hooks
Load hook: Forged Carbon steel
360° Rotation
Safe tongue
6. Push Button Control
Protection class: IP55
Emergency stop button
Compact and strength design
7.Import Contactor
Germany Schneider or
USA Eaton
Longer working life
Advantages:
1. Consist of single motor and double hooks, ensuring the hooks lift vertically and stably, this type is used for objects with two lifting points and the goods that need balances when lifting.
2.Classical design / Premium quality / High standard
1. 0.5~50 ton lifting capacity
2. With upper hook (fixed) or with trolley
3. Single/Double speed option
4. Shell: aluminum alloy
5. Chain: high quality G80
6. Chain container: canvas / iron
7. Gear & chain wheel: alloy steel + heat treatment
8. Hooks: heat forging+heat treatment
9. Chain diameter: 6.3~11.2mm (as per different capacities)
10. Motor rotate speed:1440r/min(single speed), 2880/960 r/min(double speed),
11. Standard chain length: 3m (can be customized)
12. Power specification:200~690V,50/60HZ,3 Phase
13. Safe voltage:24V/36V/48V
14. Button switch:2/4/6/8 buttons option
15. Insulation grade:F class
16. Protection class: IP55
17. Working group:M3
18. Working temperature: -40ºC ~ +40ºC
19. OEM acceptable
20. Customized logo acceptable
21. Package: plywood case
22. Warranty: 2 years for mechanical parts, 1 year for electric parts
|
Twin Hook Hoist Technical Parameters |
|||||
| Model | NCH | ||||
| 0.25+0.25t | 0.5+0.5t | 1+1t | 1.5+1.5t | 2.5+2.5t | |
| Capacity (t) | 0.5t | 1t | 2t | 3t | 5t |
|
Lifting Speed (m/min) |
7.2 | 6.6 | 6.6 | 5.4 | 2.7 |
| Motor Power(Kw) | 0.8 | 1.5 | 3.0 | 3.0 | 3.0 |
|
Rotation Speed (r/min) |
1440 | ||||
| Insulation Grade | F | ||||
| Power Supply | 3P 220V ~ 690V/50HZ | ||||
| Control Voltage | 24V/36V/48V | ||||
| No. of Chain | 2*1 | 2*1 | 2*1 | 2*1 | 2*2 |
| Spec. of Load Chain | ø6.3 | ø7.1 | ø10.0 | ø10.0 | ø11.2 |
