Product Details:
Payment & Shipping Terms:
|
| Pre-treatment:: | Shot-blasting | Bearing:: | HRB |
|---|---|---|---|
| Model Number:: | Nante Crane End Carriage | Inside Setting:: | Reinforce Plate |
| Color:: | RAL1004, Can Be Customized | Place Of Origin:: | Zhejiang, China (Mainland) |
| Driving Motor:: | Soft-starting Motor | Certification:: | ISO9001, CE, CCC |
| High Light: | overhead crane end trucks,bridge crane end trucks |
||
We are committed to provide our quality service though operational excellence and technology improvement.Electric End Carriage Steel Crane Wheels For Overhead Crane 1ton ~ 100ton.Nante has successfully developed crane kits systems for all kinds of overhead cranes.
Specifications:
Capacity: 16~22.5ton
Span: 5.5m~16.5m
Motor power: 1.1*2
Power supply: 3P, 380V, 50HZ
Speed: 19m/min, 20m/min
1~100T crane trolley-end carriage
Independently driven.
for single girder & double girder.
Low repair rate.
Tough material, high safety.
Specifications
A. Application
End carriage is applicable for wide range of cranes, such as workshop overhead bridge crane, gantry crane, etc. We are committed in providing our customers with quality and customized service.
B. Design Feature
High strength profile with reinforced plate inside
45# steel wheel group, HRC45-48.
Self-lubricating bearing
Soft start motor from Taiwan brand.
Modular design
C. Sketch Drawing
D. Technical Parameter
|
No. |
Type |
Suitable Crane |
Travel Speed (m/min) |
Power (KW) |
Wheel Dia. OD (mm) |
SI (mm) |
S2 (mm) |
W1 (mm) |
W2 (mm) |
B (mm) |
H (mm) |
|
1 |
L174-20A |
lt2t/5.5m-11.5m |
18 |
0.3x2 |
144 |
2000 |
1760 |
500 |
410 |
150 |
200 |
|
2 |
L174-25A |
lt2t/12m-16.5m |
18 |
0.3x2 |
144 |
2500 |
2260 |
500 |
410 |
150 |
200 |
|
3 |
L174-20B |
3t/5.5m-11.5m |
18 |
0.3x2 |
144 |
2000 |
1760 |
500 |
410 |
150 |
250 |
|
4 |
L174-25B |
3t/12m-16.5m |
18 |
0.4x2 |
144 |
2500 |
2260 |
500 |
410 |
150 |
250 |
|
5 |
L174-30 |
It2t3t/17m-22.5m |
18 |
0.4x2 |
144 |
3000 |
2700 |
550 |
440 |
150 |
250 |
|
6 |
L174-35 |
lt2t/23m-25.5m |
18 |
0.4x2 |
144 |
3500 |
3200 |
600 |
510 |
150 |
250 |
|
7 |
L200-20 |
5t/5.5m-11.5m |
18 |
0.4x2 |
168 |
2000 |
1600 |
600 |
510 |
150 |
250 |
|
8 |
L200-25 |
5t/12m-16.5m |
18 |
0.4x2 |
168 |
2500 |
2100 |
600 |
510 |
200 |
250 |
|
9 |
L200-30 |
5t/17m-22.5m |
18 |
0.4x2 |
168 |
3000 |
2600 |
650 |
560 |
200 |
250 |
|
10 |
L200-35 |
3t/23m-25.5m |
18 |
0.4x2 |
168 |
3500 |
3100 |
650 |
560 |
200 |
250 |
|
11 |
L240-20 |
10t/5.5m-11.5m |
19 |
0.75x2 |
208 |
2000 |
1600 |
600 |
510 |
200 |
250 |
|
12 |
L240-25 |
10t/12m-16.5m |
19 |
0.75x2 |
208 |
2500 |
2100 |
650 |
560 |
200 |
300 |
|
13 |
L240-30 |
10t/17m-22.5m |
19 |
0.75x2 |
208 |
3000 |
2600 |
650 |
560 |
200 |
300 |
|
14 |
L240-35 |
10t/23m-25.5m |
19 |
0.75x2 |
208 |
3500 |
3100 |
650 |
560 |
200 |
300 |
|
15 |
L268-25 |
16t/5.5-16.5m |
20 |
1.1x2 |
238 |
2500 |
2060 |
700 |
600 |
200 |
300 |
|
16 |
L268-30 |
16t/17m-22.5m |
20 |
1.1x2 |
238 |
3000 |
2560 |
750 |
650 |
200 |
300 |
|
17 |
L268-35 |
10t/23m-25.5m |
20 |
1.1x2 |
238 |
3500 |
3060 |
700 |
600 |
200 |
300 |
|
18 |
L268-25P |
20t/5.5m-16.5m |
19 |
1.5x2 |
238 |
2500 |
2060 |
950 |
800 |
200 |
350 |
|
19 |
L268-30P |
20t/17m-22.5m |
19 |
1.5x2 |
238 |
3000 |
2560 |
950 |
800 |
200 |
350 |
Our Service
WE can provide to customer an integrated solution which includes project consultant, design, manufacturing, transportation, installation, maintenance and technical support. Our one-stop services can not only save our customers time but also minimize their cost.
In compliance with our service concept “Customer First”, we provide the following support services to ensure smooth running of customer’s lifting and handling equipments: Presale Technical Support, After-sale Maintenance, Spare Parts Support, and Customized Solutions.
